8-35oz Fully Automatic Ultrasonic Food Paper bowl Making Machine
8-35oz Fully Automatic Ultrasonic Food Paper bowl Making Machine is a multi-station automatic forming machine which adopts automatic paper feeding, sealing (bonding wall), oil filling, bottoming, heating, knurling and crimping. Such continuous processes as well as photoelectric detection, fault alarm, counting and other functions are ideal equipment for producing large-capacity calibers or food containers such as paper soup bowls, instant noodle bowls, convenient noodle bowl, breakfast bowl,and other paper food container bowls.
Technical parameters
| Type | PF-BOWL |
| Bowl size: | 8-35oz (other customized size) |
| Max. paper bowl up diameter | 150 mm |
| Max. Paper bowl bottom diameter | 125 mm |
| Max. Paper Bowl height | 115 mm |
| Production capacity | 60-70 pcs/min |
| Power source: | 380V 50Hz(please inform us your power in advance) |
| Suitable Material: | 140-350g/m2 |
| Total Power: | 4.8 KW |
| Weight: | 1980KG |
| Machine size | 2350-1250-1900 mm |
| Air pressure | 0.6Mpa, 0.6 m3/minute |
Advantage
1.Repeatedly loose paper :Three paper feeds and multiple mediations to avoid unevenness on both sides of the paper cup
2.PLC control :The machine is more intelligent, the control is more precise, and the labor is greatly reduced.
3.Photoelectric Sensor Detection:
The encoder and the Photoelectric Sensor control the machine at the same time, a fan-shaped plate with a cup bottom to avoid paper waste. Failure alarm, automatic shutdown.
3.Bottom punching system:
In the past, the complicated paper feeding process of the bottom suction paper was prone to overturning. After improving the equipment, the direct bottom punching method was used to avoid the bottom turning in one step.
After Sale Service
1) 1 year warranty service.
2) Free replacement of parts within 1 year (free shipping).
3) Parts are provided free of charge within 2 years, but no free shipping.
4) We provide Operation & Maintenance CD.
5) When there is a problem with the machine, please take a video of the problem and send it to us.
6) We will arrange professionals to help you deal with it through video or document tutorials.
PACKAGE
| Package details | 70 pcs/min Disposable aluminum foil food paper bowl making machine |
| Package size | 2450 x 1350 x 2100 mm |
| Gross Weight | 2500 kg |
FAQ
Q1: Are you a manufacturer or a trading company?
A: We have our own factory and export team, you are welcome to visit our factory, we can take you to the airport
Q2:: Do you have a valid certificate?
A: Yes, so far we have CE, ISO, etc. we can also issue CO, Form E etc. if you wish it.
Q3: Do you inspect finished machines?
A: Yes, we have QC department, they will inspect the whole machine before packing, and provide testing video to make sure there are no problems with the machines.
Q4: What payment terms are accepted?
A: TT (Telegraphic Transfer), Western Union, MoneyGram, LC, etc.
Q5: When can the machine be shipped after ordering?
A Depending on the machine model and quantity, some stocking machines can be shipped within 3 working days after payment is cleared, some customized machines start producing after deposit arrives, please contact our staff for details.
Q6: What about warranty and after-sales service?
A: Our machines come with a two-year warranty and technical support. Help is always just a phone call or email away, then we can provide the right solution within 8 hours after analyzing and estimating the problem. Remote training and door-to-door service are available.
|
|
8-35oz Fully Automatic Ultrasonic Food Paper bowl Making Machine Images
|
